Huazheng HXGN15-12 Solid Insulated Control Switchgear Intelligent Outdoor Ring Network ຕູ້ (12kV)

Rated voltage (kV): 12

Rated current:

Load switch cabinet (A): 630

Combined electrical cabinet (A): 125

Rated short-circuit breaking current (kA): 31.5

Rated active load breaking current (A): 630

Rated short-time withstand current (kA): 20

Rated peak withstand current (kA): 50

Rated power frequency withstand voltage phase to ground, ground / fracture (kV): 42/48

Lightning impulse withstand voltage phase to ground, ground / fracture (kV): 75/85

Mechanical life: 10000 times

Rated AC current (combined electrical appliance) (A): 3150

Operation method: Manual or electric

Protection level: IP2X
