Huatec XXH-3205 Panoramic radiation portable X-ray flaw detector with glass x-ray tube
Specification:
Output voltage (Kv) | Input (KW) | Focus spot (mm) | Beam angle | Max penetration (mm) | Weight (KG) | Dimensions (mm) | |||||
Level target | Cone target | Level target | Cone target | Generator | Controller | Generator | Controller | ||||
XXH-3205 | 180-320 | 3.2 | 1.0x4.0 | 25°+5° | 30°+5° | 50 | 48 | 42 | 11 | 335x335x835 | 350x290x160 |
Standard Delivery
Directional glass X-ray tube | 1 Pcs | |
Generator | 1 Set |
|
High voltage joins cable | 1 Pcs | 25 Meters |
Controller | 1 Set |
|
Power cable | 1 Pcs | 10 Meters |
Grounding cable | 1 Pcs | 5 Meters |
Accessories | 1 Set |
|
(Including: alarm lamp,1 Pcs; lead letter, 1 box; Film dark cassettes 5 pcs; intensifying screen 5 pcs; Wire penetrameter (IQI) 1 set; fuse1 pc) | ||
