DC voltage: 0.1mV ÷ 1000V; ±(0.2%reading + 5digits)
AC TRMS, AC+DC TRMS voltage: 1mV ÷ 1000V; ±(0.8%reading + 5digits) AC; ±(2.0%reading + 20digits) AC+DC
AC TRMS current with flexible clamp F3000U: 0.01A ÷ 3000A; ±(1.0%reading + 5digits)
DC current: 0.1μA ÷ 10A; ±(1.0%reading + 3digits)
AC, AC+DC current: 0.1μA ÷ 10A; ±(1.2%reading + 5digits)
Resistance and Continuity test: 0.1Ω ÷ 60MΩ; ±(0.5%reading + 5digits)
Frequency (electronic circuits): 0.01Hz ÷ 10MHz; ±(0.09%reading + 5digits)
Frequency (electronic circuits): 40Hz ÷ 10kHz; ±0.5%reading
Duty Cycle: 0.1% ÷ 99.9%; ±(1.2%reading +2digits)
Diode test: Max 1.5mA
Temperature with K-type probe: -40°C ÷ 1000°C; 1.5%reading + 3°C
Capacitance: 0.01nF ÷ 6000μF; ±(1.2%reading + 8digits)
Functions: Data HOLD, MAX/MIN/PEAK,REL, Laser, Bluetooth, LED illuminator
Memory for data saving: micro SD card, BMP format
IR camera function
Sensor resolution: 80 x 80pxl
Temperature measuring range: -20°C ÷ 260°C / -4°F ÷ 302°F
Sensitivity: <0.1°C (@ 30°C)
Visual range (FOV): 21° x 21°
Focusing / Lens: automatic / 7mm
Image frequency: 50Hz
Mechanical characteristics
Size (L x W x H): 185 x 75 x 55mm
Weight (batteries included): 555g
Mechanical protection: IP65
Power supply
Battery type: 1x7.4V rechargeable Li-ION battery, 2300mAh
Auto power off: 15,30,60min (selectable)
Display: 4 dgt LCD, max 6000 dots, decimal sign, backlight
Provided accessories
• F3000U Flexible clamp with full scale 30/300/3000A AC
• 4413-2 Couple of red/black 4mm, 90° professional test leads
• BATMCY Spare part Li-ION battery 7.4V 1500mAh
• A0MCY Adapter multiplug for MERCURY with base charger
• Micro SD card 8GB,10x
• B0MCY Carrying case
• Alkaline battery type AAA IEC LR03, 2pcs
• Type K bead probe + adapter
• User manual
• Calibration certificate ISO9000
