Hardness Scale: HV
Hardness Conversion: HV, HR, HRC, HB, HK
Loading Force:
N: 0.098、0.246、0.49、0.98、1.96、2.94、4.90、9.80
gf: 10、25、50、100、200、300、500、1000
Indentation Measurement: Analogue Eyepiece with Mechanic Micrometer (To measure the indention by optional Vickers Testing Software system)
Loading Control: Automatic (Loading, Dwell, Unloading)
Magnification of Microscope: Observation:10x/40x; Measurement:10x/40x
Magnification on of Eyepiece: 10x Analogue Eyepiece
Dwell Time: Adjustable 5~60s
Testing Range: 1HV~3000HV
Analogue X-Y Anvil: Size:100x100mm; Travel:25 x25mm; Resolution: 0.25um
Optical Channel: Two-Channel: Eyepiece/camera switchable
Illumination: Adjustable Halogen light-source
Max. Height of Specimen: 90mm
Instrument Throat: 120mm
Operating Temperature: 23±5℃
Operating Humidity: <65%
Power Supply: AC220V/50Hz; AC110V/60Hz
Dimension (LxWxH): 530×290×490mm
Gross/Net Weight: 50Kg/40Kg
Standard Delivery：
MicroVickers Intender
X-Y Working Stage
Hardness Block (700~800) HV1
Flat Precision Clamp
Hardness Block (400~500) HV0.2
10x Analogue Eyepiece
10x Objective
40x Objective
Thin-Piece Clamp
Warranty Card / Qualified Certificate/ Operation Manual / Packing List
Dust Cover
Toolbox
Power Cord
Filament Clamp
Flat Precision Clamp
Optional Accessories：
Digital Micrometer Head
Camera Adapter
Unequal Specimen Clamp
USB CMOS Camera
Dell PC System
Vickers Measuring Software
