Hoyamo HGZ-11 Gloss Meter (0-2000Gu)

Measurement Range: 0-2000Gu

Application: Apply on paint, ink, stoving varnish, coating, wood products; Marble, granite, vitrified polished tile, pottery brick and porcelain; Plastic, paper; Other nonmetallic material.

Instrument Dimensions: 122x34x60mm

Projection Angle: 60°

Measuring Spot: （ellipse: long axis*minor axis）8mm*4mm

Output: connect the micro printer to realize real-time output of measured data

Division Value: 0.1Gu

Repeatability: 0.2Gu

Reproducibility: 0.4Gu

Indication Error: 1.0Gu

International Standard 60°: ISO－2813、ASTM－C584、ASTM－D523、DIN－67530、ASTM－D2457、JND-A60、JND-P60

National Standard 60°: GB 9754、GB 9966、GB 8807

Standard Accessories: Power adapter/user manual/warranty certification/standard board/software GlossW

Optional Accessories: micro-printer

Production Feature:

This gloss meter is designed and manufactured with the reference to the international standard ISO 2813 and China national standard GB/T9754;

Technical parameters are in accordance with ASTM D2457, ASTM D523 and GB/T13891, GB/T7706, GB/T8807 standard;

All performance indexes meet the primary working machine requirements of metrological verification procedures of national standard JJG696-2002 "mirror gloss meter and gloss board";

The delicate and light appearance is very convenient to carry and use.

Automatic calibration, no need to manual adjustment, high stability, namely the boot measurement.

All intelligent design, single bond operation, one hand can realize all operations.

Long life light source without replacement

LCD digital display, showing clear.

Built-in high capacity lithium battery can be recharged, full of electricity can measuring more than 12 hours continuously

Feature-rich, measuring accuracy, good repeatability, cost effectiveness.
