Input Characteristics:
Voltage: 220VAC,士10%, single phase
Frequency: 47-63Hz
Fuse: 8A/250VAC
DC Withstand Voltage Test: Rated Output:12KV DC
Leakage Current High Limit Setting:
Range: 0.0-5.000mA
Resolution: 0.1uA
Accuracy 士(2%setting value+2dgts)
Leakage Current Low Limit Setting:
Range: 0.00-5.000mA
Resolution: 0.1uA
Accuracy: (2% setting value+2dgts)
Voltage Setting:
Range:0-12KV DC
Resolution:1V
Accuracy:士(2% setting value +5V)
Voltage Stability: 士 (1% setting value +5V)
Ramp Time:
Range: 0.4-999.9S
Resolution: 0.1S
Accuracy: ± (0.1% setting value +0.05 S)
Test Time:
Range: 0.5-999.9S
Resolution: 0.1S
Accuracy: ± (1% setting value +0.05 S)
ARC-fault Detection: Range:1-9 level can be set, 0 arc-fault condition will not be detected
Voltage Display:
Range: 0-12KV DC
Resolution: 0.001KV
Accuracy:士(3% display value +0.005V)
Current Display:
Range: 0.0001-5.000mA DC
Resolution: 0.01mA(0. 1uA)
Accuracy:士(2% display value +3dgts)
Insulation Resistance Test: Rated output: 3500V DC
Voltage Setting:
Range: 500 – 3500V DC
Resolution:1V
Accuracy: ± (3% setting value +5V)
Voltage Display:
Range: 0.500KV –3.500KV DC
Resolution: 0.001KV
Accuracy: ± (3% display value +5V)
Resistance Value:
Range:100kΩ-99GΩ
Accuracy:
士(3% display value +3dgts) (100kΩ-9.99GΩ)
士(20% display value +3dgts) (10GΩ-99GΩ)
Resistance High/ Low Limit Setting: 100kΩ-99GΩ
Delay Time Judgment:
Range:0.1 – 999.9 S
Resolution:0.1S
Accuracy: ± (0.1% display value +0.05 S)
Grounding resistance test: Ground Resistance Tester
Output Current Setting: 10.0~100.0A (Accuracy: ± 2%)
Power Source: Max:10V/100A/1000W
Ground Resistance Upper/ Lower Limit Setting: 0 ~ 999.99 mΩ (10.00A)
0 ~ 500.0 mΩ (10.00A ~ 20.00A)
0 ~ 250.0 mΩ (30.01A ~ 40.00A)
0 ~ 200.0 mΩ (40.01A ~ 50.00A)
0 ~ 160.0 mΩ (50.01A ~ 60.00A)
0 ~ 100.0 mΩ (60.01A ~ 70.00A)
0 ~125.0 mΩ (70.01A ~ 80.00A)
0 ~100.0 mΩ (90.01A ~ 100.00A)
Accuracy: ± (2% setting value +3dgts)
Testing Time: 0.5 ~ 999.9 S, 0 is continuous testing
Time Accuracy: ±(0.1% setting value +0.05S)
