MECHANICAL
Dimensions (LxWxH):
Scanner: 108.2 mm x 70.4 mm x 160.2 mm (4.3 in x 2.8 in x 6.3 in)
Presentation Base: 82.9 mm x 90.4 mm x 121.6 mm (3.3 in x 3.6 in x 4.8 in)
Desktop/Wall Mount Base: 211.3 mm x 74.2 mm x 77.7 mm (8.3 in x 2.9 in x 3.0 in)
Weight:
Lithium-ion Scanner: 247 g / 255 g (contactless)
Battery Free Scanner: 218 g /227 g (contactless)
Presentation Base: 214 g / 220 g (contactless)
Desktop/Wall Mount Base: 223 g / 229 g (contactless)
Operating Power (Charging) Bases: 2.5W (500 mA at 5 V DC) Standard USB
10W (2A at 5V DC) – when utilizing power adapter
Non-Charging Power (Bases): 0.75W (150 mA at 5V DC)
Host System Interfaces: USB, Keyboard Wedge, RS-232
ENVIRONMENTAL
Operating Temperature:
Scanner: 0°C to 50°C (32°F to 122°F)
Bases: Charging: 5°C to 35°C (41°F to 95°F)
Non-Charging: 0°C to 50°C (32°F to 22°F)
Storage Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity: 0 % to 95 % relative humidity, non-condensing
ESD (Scanners and Cradles): ±8 kV indirect coupling plane, ±15 kV direct air
Drop: Engineered to withstand 50 drops at 1.8 m (6 ft) to concrete across operating temp range
Mil Spec Drop: 8 ft
Tumble: 2,000 at 0.5 m (1.6 ft)
Environmental Sealing (Scanner): IP52
Environmental Sealing (CCB): IP41
Light Levels: 0 – 100,000 lux
SCAN PERFORMANCE
Image Sensor: 1280 x 1080 pixel array
Motion Tolerance: 3.4 meters/second
Imager Field of View:
Horizontal: 28°; Vertical: 24°
Print Contrast: As low as 15 %
Roll, Pitch, Skew: ±360°, ±65°, ±65°
Decode Capabilities: Reads standard 1D,
PDF, 2D, Postal Digimarc, DOT Code, and OCR symbologies
Note: Decode capabilities dependent on configuration
Illumination: White 2700K
LED aimer light source: 525 nm
Image Quality: 109 PPI on an A4 document
Object Detection: Configurable
Configurable for 3” or 6” 1962 Cordless Scanner (refer to user’s manual)
WIRELESS
Radio/Range: 2.4GHz Bluetooth radio v4.2 with Adaptive Frequency Hopping. Class 1: 100 m line of sight (default), programmable to
Class 2: 10 m line of sight BLE available
POWER OPTIONS
Specifications the same for Xenon Ultra 1962
Contact and Contactless models
Battery: (based on default settings)– data based on utilization of power adapter
Capacity: 3300 mAh Li-ion (min)
Number of Scans (1scan/sec): up to 80,000 scans per charge
Expected Duration of Operation: 22 hrs
Expected Charge Time: 4.5 hrs
Battery-free Supercapactior: (based on default settings) – data based on utilization of power adapter
Expected full charge time: < 60 seconds
Number of scans fully charged: 450
Charge Cycles: 500,000
