Hirose Electric ZE05-20DP-2H(A) ປລັກຮັບສະຕິເກັດ 20ຕໍ່ 0.5 ຂະໜາດ 2mm ຊ່ອງຫຼັກ ຕໍ່ການເຊື່ອມຕໍ່ລະບົບລົດຍົນ

Color: Gray

Pitch: 2 mm (0.079 in)

Gender: Receptacle (RP - Male)

Current Rating: 2 A

Mounting Angle: Right Angle

Mounting Style: Through Hole

Number of Rows: 2 Row

Voltage Rating: 60 VAC, 60 VDC

Wire Gauge Max: 20 AWG

Wire Gauge Min: 22 AWG

Contact Plating: Tin

Contact Material: Brass

Housing Material: Polyamide (PA)

Flammability Rating: UL 94 V-0

Number of Positions: 20 Position

Description/Function: Automotive Interface

Insulation Resistance: 100 MOhms

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
