Hirose Electric EF2A-DH150B-5 ທວິສຕ໌

Color: Black

Width: 71 mm

Height: 53.95 mm

Length: 158.5 mm

Current Rating: 175 A

Mounting Style: DIN Rail Mount

Voltage Rating: 600 VAC, 600 VDC

Wire Gauge Max: 1/0 AWG

Wire Gauge Min: 4 AWG

Housing Material: Thermoplastic (TP)

Connection Method: Spring

Flammability Rating: UL 94 V-0

Number of Positions: 5 Position

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 25 C
