Hirose Electric BK13C06-16DS/2-0.35V(895) ປຸ່ມຮັບ

Pitch: 0.35 mm (0.014 in)

Application: Hybrid FPC-to-Board

Stack Height: 0.6 mm

Current Rating: 300 mA, 5 A

Mounting Angle: Straight

Number of Rows: 2 Row

Voltage Rating: 50 VAC, 50 VDC

Contact Plating: Gold

Contact Material: Copper Alloy

Housing Material: Liquid Crystal Polymer (LCP)

Termination Style: Solder

Flammability Rating: UL 94 V-0

Number of Positions: 18 Position

Insulation Resistance: 50 MOhms

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 55 C
