SPECIFICATIONS
- Measurement channels: Max 105 channels
- Recording invervals: 100 ms, 200 ms to 1 hour, 16 selections
- Data storage: 8Mwords, SD memory cad, USB memory stick
- Interface: LAN-100BSE-TX/ USB2.0
- Display device: 5.7 inch TFT color liquid crystal display
- Functions:
+ Save waveform data in real time to the SD memory card
+ USB memory stick
- Power supply:
+ Using the AC adapter Z1008 (100 to 240 V AC, 50/60 Hz)
+ Using the Battery pack Z1007
+ External power 10 to 28 V DC, 15 VA Max
- Product Net Weight:700g
- Product Size: 230*125*36mm
- Supplied accessories:
+ Instruction manual ×1, Measurement guide ×1
+ SD Memory Card (2GB) Z4001 ×1
+ CD-R (data collection software “Logger Utility”) ×1
+ USB cable ×1, AC Adapter Z1008 ×1
- The warranty period: 12 month
