Rated measurement current: 6000 A AC
Internal Measurement range: 600A AC/ 6000A AC (Range is controlled by main device)
Max. allowable input (45 Hz to 66 Hz): 10000 A continuous
Bandwidth: 10 Hz to 50 kHz (±3dB)
Amplitude and phase accuracy (45 Hz to 66 Hz) ±1.5 % rdg. ±0.25 % f.s. (f.s. is internal range)±1 deg
Output rate :1 mV/A (600 A), 0.1 mV/A (6000 A)
Loop diameter : φ 100 mm (3.94 in) or less
Output connectors: HIOKI PL 14
Dimensions: Flexible loop cable diameter: φ7.4 mm (0.29 in),
Cable length: Between flexible loop and battery box: 2.3 m (7.55 ft), Output cable: 20 cm (0.66 ft),
Battery box25 mm (0.98 in)W × 72 mm (2.83 in)H × 20 mm (0.79 in)D
Mass: 160 g (5.6 oz)
Accessories: Instruction manual ×1
