Rated current: 500 A AC/DC
Max. allowable input:
- 1000A continuous (requires derating at frequency or temperature)
- DC to 100 kHz
- Phase: DC to 100 kHz
Amplitude and phase accuracy:
- DC ±0.3 % rdg. ±0.02 % f.s. (Phase: Not defined)
- DC < f ≤ 100 Hz ±0.3 % rdg. ±0.01 % f.s. (Phase: ±0.1 deg)
- Defined to 100 kHz
Power consumption : 7 VA max. (at 500 A/55 Hz, ±12 V power requirement)
Output voltage: 4 mV/A (voltage output with the Sensor Unit 9555-10, use with a device having a 1 MΩ input resistance or higher)
Core diameter: φ 50 mm (1.79 in)
Power supply: DC ±11 V to ±15 V (Power suppled via the 9555-10, which supports 100 to 240 V AC)
Dimensions and mass: 238 mm (9.37 in)W × 116 mm (4.57 in)H × 35 mm (1.38 in)D, cord length: 3 m (9.84 ft), 870 g (30.7 oz)
Accessories: Instruction manual ×1, Mark bands ×6, Carrying Case
