- Rated measurement current: 2000 A AC/DC
- Max. measurement current: 2000 A
(requires derating at frequency))
- Max. allowable peak input: 2840 A peak
- Bandwidth: DC to 10 kHz (-3dB)
- Typical accuracy: ±2.3 deg. (DC < f ≤ 66 Hz)
- Output rate: 0.1 mV/A
- Max. rated voltage to earth: AC/DC 600 V (CAT IV)
- AC/DC 1000 V (CAT III)
- Core diameter: φ 55 mm (2.17 in) or less
- Output connectors: HIOKI PL 14
- Dimensions and mass: 64 mm (2.52 in)W × 195 mm (7.68 in)H × 34 mm (1.34 in)D, 510 g (18.0 oz), Cable length 2.5 m (8.20 ft)
- Accessories: None
| Rated measurement current | 2000 A AC/DC |
|---|---|
| Max. measurement current | 2000 A (requires derating at frequency)) |
| Max. allowable peak input | 2840 A peak |
| Bandwidth | DC to 10 kHz (-3dB) |
| Typical accuracy | ±2.3 deg. (DC < f ≤ 66 Hz) |
| Output rate | 0.1 mV/A |
| Max. rated voltage to earth | AC/DC 600 V (CAT IV) AC/DC 1000 V (CAT III) |
| Core diameter | φ 55 mm (2.17 in) or less |
| Output connectors | HIOKI PL 14 |
| Dimensions and mass | 64 mm (2.52 in)W × 195 mm (7.68 in)H × 34 mm (1.34 in)D, 510 g (18.0 oz), Cable length 2.5 m (8.20 ft) |
| Accessories | None |
