Facial Recognition
Facial Detection and Analytics: Face picture comparison, human face capture, face picture search
Face Picture Library: Up to 16 face picture libraries, with up to 50,000 face pictures in total (each picture ≤ 4 MB, total capacity ≤ 1 GB)
Facial Detection and Analytics Performance: 1-ch human face capture (HD network camera, up to 8 MP, H.264/H.265)
Face Picture Comparison: 4-ch
Motion Detection 2.0
By Device: All channels, 4 MP video analysis for human and vehicle recognition to reduce false alarm
By Camera: All channels
Perimeter Protection
Human/Vehicle Analysis: 2-ch, 4 MP (HD network camera, up to 8 MP, H.264/H.265) video analysis for human and vehicle recognition to reduce false alarm
Video and Audio
IP Video Input: 32-ch
Incoming Bandwidth: 256 Mbps
Outgoing Bandwidth: 160 Mbps
HDMI 1 Output: 4K (3840×2160)/60 Hz, 4K (3840×2160)/30 Hz, 1920×1080/60 Hz, 1600×1200/60 Hz, 1280×1024/60 Hz, 1280×720/60 Hz, 1024×768/60 Hz
HDMI 2 Output: 1920×1080p/60 Hz, 1280×1024/60 Hz, 1280×720/60 Hz, 1024×768/60 Hz
VGA 1 Output: 1920 × 1080p/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
VGA 2 Output: 1920 × 1080p/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
Video Output Mode
HDMI 1 and VGA 1 provide simultaneous video output, and work as the main output;
HDMI 2 and VGA 2 provide simultaneous video output, and work as the auxiliary output
Audio Output: 2-ch, RCA (Linear, 1 KΩ)
Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)
Decoding
Decoding Format: H.265+/H.265/H.264+/H.264
Recording Resolution
12 MP/8 MP/6 MP/5 MP/4 MP/3
MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous playback: 16-ch
Decoding Capability
AI on: 1-ch@12MP (30fps)/2-ch@8 MP (30 fps)/4-ch@4 MP (30 fps)/8-ch@1080p(30 fps)
AI off: 2-ch@12MP (30fps)/3-ch@8 MP (30 fps)/6-ch@4 MP (30 fps)/12-ch@1080p(30 fps)
Stream Type: Video, Video & Audio
Audio Compression: G.711ulaw/G.711alaw/G.722/G.726/AAC
Network
Remote Connection: 128-ch
Network Protocol: TCP/IP, DHCP, IPv4, Hik-Connect, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS
Network Interface: 2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Auxiliary Interface
Serial Interface: 1 RS-232, 1 RS-485
SATA: 8 SATA interfaces
eSATA: 1 eSATA interface
Capacity: Up to 10 TB capacity for each disk
Alarm In/Out: 16/9, the 9th alarm supports control 12V.
USB Interface: Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
Power output: 12V DC
General
Power Supply: 100 to 240 VAC, 50 to 60 Hz
Consumption: ≤ 30 W (without HDD)
Working Temperature: -10 °C to 55 °C (14 °F to 131 °F)
Working Humidity: 10 to 90 %
Dimension (W × D × H): 441×457×91 mm (17.4"×18.0"×3.6")
Weight: ≤ 8 kg (17.6 lb)
