Acoustic specificatons
Number of microphones: 64
Bandwidth: 2 khz to 60 khz
Distance: 0.2m to 100 m
Acoustic image palette: 8: white black, black white, rainbow, fusion, ironbow, red black, rain, blue red
Sound intensity display: peak point, center point
Acoustic detection mode: partial discharge detection, gas leakage detection
Acoustic image frame rate : 25 fps
Optical module
Built-in visual camera: 2688 x 1944 (5 mp)
Fov ( field of view): 53° (h) x 28° (v)
Picture resolution: 800 x 480
Video resolution: 800 x 480
Focal length: 6.4 mm
Image display
Display: 800 x 480 resolution, 4.3" LCD touch screen
Screen brightness: manual/automatically adjust
Power saving mode: standby mode, off
Digital zoom : 1.0x to 8.0x continuous
Storage
Storage media: default storage: removable sd card (64 gb) max. Storage capacity: 128 gb
Image storage capacity: 60,000 images
Voice note: max. 60 seconds
Text note: max. 200 characters
Video storage capacity: 54 hours
Video file format: mp4
Power system
Power supply: 12 vdc/1.5a, 5 vdc/2a (charging via usb)
Power consumption: 5.2w
Battery type: dismountable and rechargeable li-ion battery
Battery operating time: 4 hours continuous running
Battery charging time: 4 hours to full charge
Battery charging system: two-bay battery charger or in-imager charging, fast charging
Ac operation: AC operation with included power supply 1100 VAC to 240 VAC, 50/60 hz
General
Wi-fi: 802.11 b/g/n (2.4 ghz and 5 ghz)
Usb interface: ÚB type-C
Sd card interface: SD card
Hdmi interface: HDMI-D
Protection level: IP40
Drop test height: 1.2 m (3.94 ft)
Warranty: 3 years for full product and 2 years for battery
Vibration: 0.03 g2/hz (3.8 g), 2.5 g iec 60068-2-6
Shock: 25g, iec 68-2-29
Working temperature range: -20°c to 50°c (-4f to 122°f)
Storage temperature range: -20°c to 60°c 1-4°f to 140°f)
Relative humidity: < 95% non-condensing
Weight: approx. 940 g (2.07 lb)
Dimension: 292.2 mm x 127mm x 110.7 mm (11.50" x 5.00" x 4.36")
Tripod mounting: unc 1/4" - 20
Menu language: 21 languages
