THERMAL MODULE
DETECTOR TYPE: Vanadium Oxide Uncooled Focal Plane Array
IR RESOLUTION: 640 × 480 (307,200 pixels)
DETECTOR PITCH: 17 μm
SPECTRAL RANGE: 7.5 to 14 μm
NETD: < 30 mK (@ 30 °C, F#=1.0)
FOV (FIELD OF VIEW): 50.0° H × 37.3° V
IMAGE FREQUENCY: 30 Hz
FOCAL LENGTH: 12.6 mm
FOCUS: Continuous Autofocus/Autofocus/Manual Focus/Laser Assisted Focus
FOCUS SPEED: Approx. 1 second
MINIMUM FOCUS DISTANCE: 0.15 m (0.49 ft)
INTERCHANGEABLE LENS OPTIONS: Yes
LENS RECOGNITION: Automatic
IFOV (SPATIAL RESOLUTION): 1.35 mrad
F-NUMBER: F1.0
OPTICAL MODULE
BUILT-IN VISUAL CAMERA : 3264 × 2448 (8 MP)
FOCUS: Fixed
FOV: 65° H × 51° V
PICTURE RESOLUTION: Configurable: 2 MP, 5 MP, 8 MP
VIDEO RESOLUTION: 960 × 720
IMAGE DISPLAY
DISPLAY: 1280 × 720 Resolution, 5” LCD Touch Screen
SCREEN BRIGHTNESS: Manual/Automatically adjust
LENS ROTATION: 180°
DISPLAY ROTATION: 90°
VIEWFINDER: Built-in 1024 × 768 pixels
DIGITAL ZOOM: 1.x to 12.x continuous
COLOR PALETTES: 7: White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Rain
IMAGE MODES: Thermal/Optical/Fusion/PIP
PIP: Resizable and movable infrared area on the visual image
FUSION: Thermal image with visual camera details
LEVEL/SPAN : Auto/Manual/1-Tap Touch-Screen
MEASUREMENT AND ANALYSIS
Temperature Range Setting:
Range 1: -40°C to 150°C
Range 2: 0°C to 650°C
Auto Switch
ACCURACY: Max. (± 2°C/3.6°F, ± 2%)
MEASUREMENT PRESETS: Center Spot, Hot Spot, Cold Spot, Off
USER-DEFINED MEASUREMENT POINTS: 10 points
USER-DEFINED MEASUREMENT LINES: 1 line with Max./Min./Avg. temperature
USER-DEFINED MEASUREMENT AREAS: 3 areas with Max./Min./Avg. temperature
HIGH TEMPERATURE ALARM: Audible/visual alarm of above temperature threshold, User-defined temperature threshold
ON-CAMERA EMISSIVITY CORRECTION: Variable from 0.01 to 1.0 or selected from the materials list
ON-CAMERA REFLECTED TEMPERATURE COMPENSATION: Automatic, based on the input of the reflected temperature
ON-CAMERA TRANSMISSION CORRECTION: Automatic, based on the inputs for distance and humidity
DATA STORAGE
STORAGE MEDIA : Default Storage: Removable Card (64 GB); Max. Storage Capacity: 128 GB
IMAGE STORAGE CAPACITY : Approx. 60,000 images (The size of a single image is about 900 KB to 1.3 MB)
IMAGE FILE FORMAT: Radiometric image with measurement data included; JPEG image without measurement data included
VOICE NOTE: Max. 60 seconds
TEXT NOTE: Max. 200 characters
VIDEO STORAGE CAPACITY: Approx. 64 h (The size of a one-minute video is about 15 MB to 20 MB)
VIDEO FILE FORMAT: Standard MP4 non-radiometric video
SOFTWARE
PC SOFTWARE HIKMICRO: Analyzer
APP HIKMICRO: Viewer App
CAST SCREEN UVC : Alarm Client
BATTERY
POWER SUPPLY: 12 VDC/3 A, 5 VDC/3 A (Charging via USB), fast charging
BATTERY TYPE: Dismountable and rechargeable Li-ion battery
BATTERY OPERATING TIME: 4 hours continuous running per battery (actual life varies depending on settings and usage)
BATTERY CHARGING TIME: 2.5 h to full charge
BATTERY CHARGING SYSTEM: Two-bay battery charger or in-imager charging, fast charging
AC OPERATION AC: operation with included power supply (100 VAC to 240 VAC, 50/60 Hz)
GENERAL
WI-FI : 802.11 b/g/n (2.4 GHz)
BLUETOOTH: Bluetooth 4.2
USB INTERFACE: USB Type-C
HDMI INTERFACE: HDMI-D
SD CARD INTERFACE: 64 GB SD card
LED LIGHT (TORCH): Yes
LASER POINTER: Yes
LASER DISTANCE METER: Indoor distance: 50 m (164 ft); Outdoor distance: 10 m (33 ft).
LASER TYPE: Class II, Wavelength: 635 nm; Power: < 1 mW
GEOLOCATION: Location data automatically added to every image from the built-in GPS, BDS, GLONASS or GALILEO
COMPASS: Camera direction automatically added to every image
CARRYING CASE: Yes
PROTECTION LEVEL: IP54 (protected against dust, limited ingress; protection against water spray from all directions)
WARRANTY: 3 years for whole product, 10 years for detector, and 2 years for battery
RECOMMENDED CALIBRATION CYCLE: 1 year (assumes normal operation and normal aging)
SAFETY IEC 61010-1: Overvoltage Category II, Pollution Degree 2
ELECTROMAGNETIC COMPATIBILITY: EN55032: 2015+A11: 2020; EN50130-4: 2011+A1: 2014; EN61000-3-3: 2013
AUSTRALIAN RCM: EN 61010-1: 2010; EN55032: 2015+A11: 2020; EN50130-4: 2011+A1: 2014;EN61000-3-3: 2013
ROHS COMPLIANT: Yes
VIBRATION: 0.03 g2/Hz (3.8 g), 2.5 g IEC 60068-2-6
SHOCK: 25 g, IEC 68-2-29
WORKING TEMPERATURE RANGE: -20°C to 50°C ( -4°F to 122 °F)
STORAGE TEMPERATURE RANGE: -20°C to 60°C ( -4°F to 140°F)
RELATIVE HUMIDITY: < 95% non-condensing
WEIGHT: Approx. 1590 g (3.51 lb)
DIMENSION: 204.7 mm × 149.7 mm × 87.8 mm (8.06” × 5.89” × 3.46”)
TRIPOD MOUNTING: UNC ¼”-20
LANGUAGE : 21 Languages
