Infrared Image
IR Resolution: 192 × 144 (27,648 pixels)
SuperIR: 384 × 288 (110,592 pixels)
NETD: <40 mK (@ 25°C, F#=1.0)
Image Frequency: 25 Hz
Detector Pitch: 12 μm
Spectral Range: 7.5 μm to 14 μm
Focal Length: 6.9 mm
F-number: F1.0
Field of View (FOV): 18.8° × 14.1° (H × V)
Spatial Resolution (IFOV): 1.74 mrad
Min. Focus Distance: 0.1 m (1.33 ft)
Focus Mode: Manual Focus
Image Display
Visual Camera: 3264 × 2448 (8 MP)
Display: 640 × 480 Resolution, 3.5" LCD Touch Screen
Screen Brightness: Manual
Digital Zoom: 1.0× to 8.0× continuous
Color Palettes: White Hot, Black Hot, Rainbow, Ironbow, Red Hot, Fusion, Rain, Blue Red
Focus Mode Palette: N/A
Color Alarm: N/A
Image Modes: Thermal/Visual/Fusion/PIP/Blending
Measurement and Analysis
Object Temperature Range: -20°C to 550°C (-4°F to 1022°F)
Accuracy: Max (± 2°C/3.6°F, ± 2%), for the ambient temp. 15°C to 35°C (59°F to 95°F) and object temp. above 0°C (32°F)
Measurement Tools: Center Spot, Hot Spot, Cold Spot
User-definable: 10 spots, 1 line, 5 rectangles, and 5 circles
Level and Span Mode: Auto/Manual/1-Tap Touch-screen
Data Storage and Communication
Storage Media: Removable 16 GB Micro SD Card
Image Storage Capacity: Approx. 60,000 Images
Annotations: Voice note: Max. 60 seconds; Text note: Max. 200 characters
Video Storage Capacity: Approx. 15 hours
Video File Format: MP4 video
General
Wi-Fi: 802.11 b/g/n (2.4 GHz and 5 GHz)
Bluetooth: Bluetooth 4.2
USB Interface: USB Type-C
LED Light: Yes
Laser: Yes, Class II, Wavelength: 635 nm; Power: < 1 mW
Battery Type: Interchangeable and rechargeable Li-ion battery
Battery Operating Time: Approx. 6 hours
Battery Charging Time: Approx. 4 hours fully charged
Protection Level: IP54
Drop Test Height: 2 m (6.56 ft)
Safety: IEC 61010-1
EMC: EN 50130-4, EN 55032, EN IEC 61000-3-2, EN 61000-3-3
Vibration: 1 g, IEC 60068-2-6
Shock: 15 g, IEC 60068-2-27
Working Temperature Range: -10°C to 50°C (-4°F to 122°F)
Storage Temperature Range: -20°C to 70°C (-4°F to 158°F)
Relative Humidity: < 95% non-condensing
Weight: Approx. 660 g (1.46 lb)
Dimension: 244 mm × 100 mm × 104 mm (9.6" × 3.9" × 4.1")
Tripod Mounting: UNC ¼”-20
