Thermal Module
Image sensor: Uncooled Focal Plane Arrays
Max. Resolution: 640 × 512@25fps
Pixel Pitch: 17μm
Response waveband: 8μm to 14μm
NETD: < 40mk (@25°C,F#=1.0)
Lens (focal length): 35mm
MRAD (IFOV: ) 0.486
Field of View: 17.7° × 14.2°
Aperture: F 1.0
Digital Zoom: 4×
Optical Module
Image Sensor: 1/3” Progressive Scan CMOS
Min. Illumination: B/W : 0.001 lux @ (F1.0 , AGC On )
Max. Resolution: 1280 × 960@25fps
Lens (focal length): 12mm, Manual focus
Image Enhancement: 3D DNR, Adaptive AGC
Image Display
Monitor: 0.39-inch, OLED, 1024 ×768
Thermal/Optical Mode: Thermal view, B/W optical view, image fusion view are selectable
Image Fusion: Color fusion, B/W fusion
Palettes: Black hot, white hot
Power Supply
Battery Type: Four 18650 batteries, requires 5 hours to be fully charged
Battery Operating Time: ≥7h
Battery Capacity Display: Yes
General
Power: 5V DC/2A
Working Temperature: -30 °C to 55 °C (-22 °F to 131 °F)
Protection level: IP67
Mounting : UNC 1/4”-20
Cable Output : Aviation plug: connecting to BNC, DB9, and USB
Accessories (Supplied): Battery charger, battery charger power cable, wiping cloth, two wrist straps, User manual, aviation plug cable, eight batteries
Dimension (L x W x H): 164mm × 182.3mm × 73.3mm (6.46" × 7.18" ×2.89")
Weight: <1.0kg (2.20 lb)
