THAY THẾ BẰNG MODEL B20S
Thermal Module
Image sensor: Vanadium Oxide Uncooled Focal Plane Arrays
IR resolution: 256 x 192 (49, 152 pixels)
Pixel pitch: 12μm
Spectrum range: 8-14μm
NETD: < 40mK (@25°C, F#=1.0)
Focal length: 3.6mm
FOV (Field of View): 37.2°×50°
Image frequency: 25Hz
Focus: Fixed
IFOV (Spatial Resolution): 3.3 mrad
Aperture: F1.0
Minimum focus distance: 0.3 m (0.98 ft)
Optical Module
Picture resolution: 1600 × 1200 (2 MP)
FOV: 55°× 42°
Focal length: 2mm
Image Display
Display: 240 × 320 Resolution, 3.2’’ LCD Screen
Color Palettes: White Hot, Black Hot, Rainbow, Ironbow
Image Modes: Thermal/Optical/Fusion/PIP
PIP: Thermal Picture in Optical Picture
Fusion: Thermal Picture and Optical Picture Combined
Measurement and Analysis
Object Temperature Range: 20°C to 550°C (-4°F to 1022°F)
Accuracy: Max. (± 2°C/3.6°F, ± 2%), for ambient temperature 15°C to 35°C (59°F to 95°F) and object temperature above 0°C (32°F)
Measurement Presets: Center Spot, Hot Spot, Cold Spot, Point Presets, Off
High Temperature Alarm: Audible and Visual Warning
Storage
Storage media: EMMC (16 GB)
Image storage capacity: 90 000 Images
Image file format: BMP with Measurement Data Included
Functions
LED Light: Yes
Wi-Fi: No
UVC Cast Screen: Yes
Level/Span: Auto/Manual
Power System
Power supply: 3.7 V DC/0.5 A
Power consumption: 1.8 W
Battery type: Rechargeable Li-ion Battery
Battery operating time: 6 Hours Continuous Running
Battery charging time: 3 Hours
General
Menu language: 21 Languages
Working temperature range: -10°C~50°C (14°F~122°F)
Storage temperature range: -20°C~60°C (-4°F~140°F)
Protection level: IP54
Drop Test Height: 2 m (6.56 ft)
Interface: USB Type-C
Weight: Approx. 380 g (0.84 lb)
Dimension: 221.7 mm × 73.5 mm × 80.6 mm (8.73” × 2.89” × 3.17”)
Tripod Mounting: UNC ¼”-20
