Test Freq: 20Hz~500kHz (10mHz step)
Basic Accuracy: 0.05%
Equivalent Circuit: Series, Parallel
Comparator: Upper and Lower test limits in units and percentage
Test mode: Auto, Continued, Manual
Touch mode: Internal, Manual, External
Test speed (≥1kHz)
+ Fast: 75t/sec
+ Medium: 12t/sec
+ Slow: 3t/sec
Average number: 1~255
Delay Time: 0~60s, 1ms step
Calibration: open/ short/ load
Test configuration: Five end
Display mode: Δ, Δ%, V/I (Voltage/ current monitoring)
LCD: 7' LCD
Test signal:
+ Freq.: 20Hz~500kHz
+ Output impedance: 30Ω,100Ω,50Ω, 10/CC
+ Test Volt.: 5mV~2V; Accuracy: 10%
+ Memory: 100 (Internal). 500 (External)
+ Interface: RS232C. HANDLER, USB HOST (OPTION GPIB)
Temp. Humidity: 0~40°C, ≤90%RH
Power Volt.: 110V±10%; or 220±10%
Power Freq.: 47.5Hz~63Hz
Power consumption: ≤80VA
Size (W×H×D): 398×129×370mm
Weight: ≈9kg
