Test Freq: 50Hz,60Hz,100Hz,120Hz,1kHz,10kHz,20kHz, 40kHz, 50kHz,100kHz (10 points)
Basic Accuracy: 0.05%
Equivalent Circuit: Series, Parallel
Comparator: Upper and Lower test limits in units and percentage
Test mode: Auto, Continued, Manual
Touch mode: Internal, Manual, External
Test speed (≥1kHz)
+ Fast: 40t/sec
+ Medium: 11t/sec
+ Slow: 3t/sec
Average number: 1~255
Delay Time: 0~60s, 1ms step
Calibration: open/ short/ load
Test configuration: Five end
Display mode: Δ, Δ%, V/I (Voltage/ current monitoring)
LCD: 4.3' LCD
Test signal:
+ Freq.: 50Hz~100kHz
+ Output impedance: 30Ω,100Ω (Select)
+ Test Volt.: 0.1V, 0.3V, 1V; Accuracy: 10%
+ Memory: 100 (Internal). 500 (External)
+ Interface: RS232C. HANDLER, USB HOST (OPTION GPIB)
Temp. Humidity: 0~40°C, ≤90%RH
Power Volt.: 110V±10%; or 220±10%
Power Freq.: 47.5Hz~63Hz
Power consumption: ≤30VA
Size (W×H×D): 240x90x310mm
Weight: ≈2.5kg
