Technical Parameter
AC current output range: 30A / phase or 180A (three phase parallel)
DC current output range: 10A DC /phase
AC voltage output range: 120V AC /phase
DC voltage output range: 160V DC / phase
Frequency range ( fundamental): 0~1000Hz
Time measuring range: 0.1ms ~ 9999s
accuracy of measurement: <0.1ms
Size: 440mm*380mm*190mm
Nominal parameter
AC current output
Phase current output (effective value): 0~40A, Output Precision 0.2 degree
3 phase parallel current output (effective value): 0~120A
A Long-time Phase current: 10A
Maximum output power of Phase current: 450VA
Maximum output power of 3 parallel current: 900VA
Maximum Permitted work time of 3 parallel current: 10S
Frequency range ( fundamental): 0~1000Hz
Harmonic time: 0~20
DC current output
Current output: 0～±10A / phase, 0～±30A / 3 parallel
Output Precision： 0.5 degree
AC voltage output
Phase voltage output (effective value): 0~120V Output Precision 0.2 degree
Line voltage output (effective value): 0~240V
Phase voltage / Line phase output power: 80VA / 100VA
Frequency range (fundamental): 0~1000Hz
Harmonic time: 0~20
DC voltage output
Phase voltage output range: 0～±160V Output Precision 0.5 degree
Line voltage output range: 0～±320V
Phase voltage / Line phase output power: 70VA / 140VA
10 path digital input and 8 path digital output
Time measuring range： 0.1ms ～ 9999s ，accuracy of measurement ＜0.1ms
Volume & weight ：400×360×160mm³ ，15kg
