Bandwidth: 200MHz
Number of channels: 2
Real-time sampling rate: 1GSa/s
Equivalent sampling rate: 25GSa/s
Memory depth: 40K
Rise time: 1.7ns
Time base accuracy: 50ppm
Time range: 2ns/div-5V/div
Input impedance: 1MΩ
VOLTS/DIV range: 2mV/div-5V/div
A/D converter: 8-bit
Position range:
50V (5V/div)
40V (2V/div-500mV/div)
2V (200mV/div-50mV/div)
400mV (20mV/div-2mV/div)
Achievable accuracy (DC):
3% from 5V/div to 10mV/div
4% from 5mV/div to 2mV/div
Bandwidth limit: 20MHz
Trigger types: Edge, pulse, video, slope, overtime, alternate
Trigger sources: CH1, CH2, EXT, EXT/5, AC Line
Math functions: +, -, ×, ÷, FFT
Cursor measurements:
Voltage difference between cursors: V
Time difference between cursors: T
Symmetry of T in Hertz (1/T)
Automatic measurements: Frequency, Period, Mean, Peak-Peak, Cycle RMS, Minimum, Maximum, Rise time, Fall time, Negative pulse width, Positive pulse width, Delay 1-2 Rise, Delay 1-2 Fall, +Duty, -Duty, Vbase, Vtop, Vmid, Vamp, Overshoot, Preshoot, Period Mean, Period RMS, FOVShoot, RPREShoot, BWIDTH, FRF
Display: 7" TFT 16K Color LCD, 800x480 dots
Dimensions: 313 x 108 x 142mm
Weight: 3.0KG
Standard probes: PP200 x 2
