Technical Parameter of DC Voltage Output:
Measurement Limit: 75mV, 300mV, 1V, 3V, 10V, 30V, 100V, 300V,1000V
Regulating Range: 0 ～ 110％ RG
Regulating Fineness: 0.01％ RG
Accuracy: ±(0.03%RG+0.02%RD)
Ripple Coefficient: ≤0.1%
Maximum Load: 20mA; 50mA(1000V)
Technical Parameter of DC Current (Table 1):
Measurement Limit: 100uA, 200uA,1mA, 2mA,10mA, 20mA, 100mA, 200mA, 1A, 2A
Regulating Range: 0 ～ 110%RG
Regulating Fineness: 0.01%RG
Accuracy: ±(0.03%RG+0.02%RD)
Ripple Coefficient: ≤0.2%
Maximum Load: 8V
Technical Parameter of DC Current (Table 2):
Measurement Limit: 10A, 25A, 50A, 100A
Regulating Range: 0 ～ 110%RG
Regulating Fineness: 0.01%RG
Accuracy: ±(0.03%RG+0.02%RD)
Ripple Coefficient: ≤0.2%
Maximum Load: 2V
Technical Index of Power:
Output Range: 1W ～ 25kW
Accuracy: 0.0005
Other Technical Index:
Power Supply: AC(220±22)V, (50±2)Hz
Net Weight: ≤15kg
Dimension: 472 × 445 × 135mm (W × D × H)
Ambient Operation Temperature & RH: 15℃～ 30℃ , 30% ～ 80%RH
Ambient Storage Temperature & RH: -20℃～ 70℃ , ＜ 95%RH
Note: The final dimension and weight of package are subject to each lot of production
