Measuring (mm): 400x300x200
Dimension (mm): 1400x1020x1600
Instrument weight (kg): 500
Accuracy: X,Y： (2.8+L/200) μm
Z： (5+L/200) μm
Repeat-ability: 3μm
Grating ruler resolution: 0.001mm
CCD: 1/3"High-resolution color CCD 600TV line(SONY Chip)
Zoom lens: 0.75～4.5X high-definition manual zoom lens
Image magnification: 36～220X
Working distance: 92mm
Measuring software: HUD-CNC
Upper light source: Adjustable 6 ring 8 area surface ring LED cold light source
Under light source: Parallel light design, Promise continuously adjustable LED cold light source
Motor: 200W servo motor
Guide rails: High precision linear guide made in Taiwan
Mode of operation: Program control or joystick
Operating Voltage: Single phase, 220V (AC) 50Hz
