GYS PROGYS 200E FV CEL ເຄື່ອງເຊື່ອມ MMA ແລະ TIG DC (1ph; 230V; 5-200A)

INVERTER TECHNOLOGY, MICROPROCESSOR CONTROLLED WELDING UNIT WITH KEYBOARD AND DIGITAL DISPLAY. MULTI-PURPOSE EQUIPMENT, WILL WORK ON A 16A-230V - POWER SUPPLY EVEN FOR INTENSIVE USE.

MMA:

With its high duty cycle and revolutionary arc dynamics, it will weld any kind of electrodes (Ø1.6 & 5 mm): steel, stainless steel, cast iron, rutile, basic, aluminum or cellulosic. This product ensures a stable arc with a constant intensity and features the following technology:

+ Anti-Sticking

+ Adjustable Hot Start: Makes it easier to arc with any type of metal (Low Hot Start: For thin metal sheets – high Hot Start for metals that are difficult to weld such as dirty or oxidized sheets)

+ Adjustable Arc force: For better penetration and prevention of sticking.

TIG LIFT:

Equipped with a TIG torch with valve (option), this machine ensures you to have a smooth welding line.

- TIG Lift: The arc is created by touching the metal with the tungsten electrode - avoiding tungsten inclusions and radio electrical disturbances.

- Automatic arc release: This innovative function allows the operator to finish welding without creating craters. The time is adjustable and the function is activated by a movement of the torch

Specifications:

Power supply: 230 V, 1 ph, 50/60 Hz

Fuse: 16 A

Normal current output (MMA): 5-200 A

Normal current output (TIG): 5-200 A

Maximum welding current: 200 A

No-load voltage: 108 V

Duty cycle (environment temperature at 40°C):

- MMA:

200 A/28 V @ 25%

135 A/25.4 V @ 60%

115 A/24.6 V @ 100%

- TIG:

200 A/18 V @ 35%

165 A/16.6 V @ 60%

135 A/15.4 V @ 100%

Dimensions (L x w x h): 44x37x27 cm

Weight: 9 kg

Protection class: IP21

Standard: IEC 60974-1/10 A

Included accessories:

- Earth clamp (3m/ø 25mm²)

- Electrode holder (3m/ø 25mm²)

- Plastic case
