Voltage: 1.5V~150V
Current 0~1890A
Power 9450W
Operating Range 0~1890A; 0~189A
Accuracy of Setting: ±(0.2 % of set + 0.1 % of f.s*1) + Vin*2/500 kΩ
Constant Resistance Mode
Operating Range:1260.0144S~21.6mS (793.641uΩ~46.2963Ω)
126.00144S~2.16mS (7.93641mΩ~462.963Ω)
Accuracy of Setting ±(0.5 % of set*4 + 0.5 % of f.s.*3) + Vin*2/500 kΩ
Resolution: 21.6mS ; 2.16mS
Constant Voltage Mode:
Operating Range: 1.5V~150V/ 1.5V~15V
Accuracy of Setting: ±(0.1 % of set + 0.1 % of f.s)
Resolution 10mV / 1mV
Constant Power Mode:
Operating Range:945W~9450W/ 94.5W~945W
Accuracy of Setting: ±(0.6 % of set + 1.4 % of f.s*3)
Resolution 900mW; 90mW
Voltmeter Accuracy ±(0.1 % of rdg + 0.1 % of f.s)
Ammeter Accuracy ±(0.2 % of rdg + 0.3 % of f.s)
Power Source AC100V ~ 230V±10% ; 50Hz / 60Hz ± 2Hz
Interface USB/RS232C/Analog Control (Standard) ; GPIB(Option)
Weight Approx.149 kg
DIMENSIONS & WEIGHT 598(W)x877(H)x706(D)mm
