Voltage: 1.5V~150V
Current 0~1470A
Power 7350W
Operating Range 0~1470A ;0~147A
Accuracy of Setting: ±(0.2 % of set + 0.1 % of f.s*1) + Vin*2/500 kΩ
Constant Resistance Mode
Operating Range: 980.0112S~16.8mS (1.02039mΩ~59.5238Ω)
98.00112S~1.68mS (10.2039mΩ~595.238Ω)
Accuracy of Setting ±(0.5 % of set*4 + 0.5 % of f.s.*3) + Vin*2/500 kΩ
Resolution: 16.8mS ; 1.68mS
Constant Voltage Mode:
Operating Range: 1.5V~150V/ 1.5V~15V
Accuracy of Setting: ±(0.1 % of set + 0.1 % of f.s)
Resolution 10mV / 1mV
Constant Power Mode:
Operating Range:735W~7350W/ 73.5W~735W
Accuracy of Setting: ±(0.6 % of set + 1.4 % of f.s*3)
Resolution 700mW; 70mW
Voltmeter Accuracy ±(0.1 % of rdg + 0.1 % of f.s)
Ammeter Accuracy ±(0.2 % of rdg + 0.3 % of f.s)
Power Source AC100V ~ 230V±10% ; 50Hz / 60Hz ± 2Hz
Interface USB/RS232C/Analog Control (Standard) ; GPIB(Option)
Weight Approx.125 kg
DIMENSIONS & WEIGHT 598(W)x877(H)x706(D)mm
