Output Rating
Rated power: ± 5000 W
Rated voltage (source): 0 V to 100 V
Operating voltage (sink): 5 V to 100 V
Rated current: ± 170 A
Output Voltage
Maximum settable voltage: 100 V
Load regulation CV: 0.05 % FS
Line regulation CV: 0.015 % FS
Temperature coefficient CV: 100 ppm
Remote sensing (compensation voltage): 5 V
Output Current
Settable maximum source current: 170A
Settable maximum sink current: -170A
Load regulation CC: 0.2 % FS
Line regulation CC: 0.05 % FS
Ripple and noise (rms): 0.1 % FS
Temperature coefficient CC: 200 ppm
Output Power
Settable maximum source power: 5000W
Settable maximum sink power: -5000W
DC Output Resistor range: 0 Ω to 100 Ω
Protective Functions
OVP: 0% FS to 110% FS
OCP: 0% FS to 110% FS
OTP, Vsense reverse protection, Input voltage protection (OVP, UVP)
400 V Three-phase Three-wire Input
Nominal input rating: 380 Vac to 460 Vac
Input voltage range: 342 Vac to 510 Vac
Input frequency range: 47 Hz to 63 Hz
Output Power: 5000 W
Input current (MAX) at 342 Vac: 9.2A
Input power (MAX): 5.5kVA
General Specifications
Operating temperature: 0 °C to 40 °C
Operating humidity: 20 % to 90 % RH
Storage temperature: -10 °C to 70 °C
Storage humidity: 20 % to 90 % RH
Altitude: 1000 m
Dimensions (W x H x D) mm: 482 mm × 133.3 mm × 790 mm
Weight: 24kg
