DC Output Mode
Output voltage: 10.000V
Output current: 5.0000A
Output power: 50W
CONSTANT VOLTAGE OPERATION
Line regulation: ±(0.01% of setting +1mV)
Load regulation: ±(0.01% of setting +2mV)
CONSTANT CURRENT OPERATION
Line regulation: ±(0.02% of setting + 250uA)
Load regulation: ±(0.02% of setting + 250uA)
Measurement and Display
Voltage Range: H 10.000V
L 1.0000V
Current Range
H 5.0000A
M 500.00mA
L 50.000mA
LL 5.0000mA
Dimensions (mm) & Weight: 107(W)×124(H)×313(D) (not including protrusions)，Approx. 5.5kg
Operating temperature: 0˚ C to 40˚ C
Storage temperature: -20˚ C to 70˚ C
Operating humidity: 20% to 80% RH; No condensation
Storage humidity: 20% to 85% RH; No condensation
Standard Accessories
CD (User Manual) x 1, Power Cord x 1, Test Lead x 1
Optional Accessories
GTL-258 GPIB Cable, 2000mm
GTL-259 RS-232 Cable with DB9 Connector to RJ45
GTL-260 RS-485 Cable with DB9 Connector to RJ45
GTL-262 RS-485 slave cable
GTL-246 USB Cable(USB 2.0 Type A-Type B Cable, 4P
GTL-205A Temperature probe Adapter (thermal coupling, K-Type), about 1000mm
GRA-441-J Rack for PPX Series(JIS)
GRA-441-E Rack for PPX Series(EIA)
PPX-G GPIB Interface(factory installed)
