GW INSTEK PHU 80-170 ແຫຼ່ງພະລັງງານ DC ກຳລັງສູງ (80 V, 170A, 5000W)
Rated output voltage: 80 V
Rated output current: 170 A
Rated output power: 5000 W
Output power ratio: 2.72
Constant Voltage Mode
Line regulation [0.01 % of Vo_rated]: 8 mV
Load regulation [0.02 % of Vo_rated]: 16 mV
Ripple and noise p-p: 200 mV
Ripple and noise r.m.s.: 16 mV
Temperature coefficient: 100 ppm/°C
Remote sense compensation voltage (5 % of Vo_rated): 4 V
Rise time
Rated load: 30 ms
No load: 30 ms
Fall time
Rated load: 80 ms
No load: 1000 ms
Transient response time: 1.5 ms
Constant Current Mode
Line regulation [0.05 % of Io_rated]: 85 mA
Load regulation [0.1 % of Io_rated]: 170 mA
Ripple and noise r.m.s.: 170 mA
Temperature coefficient: 100 ppm/°C
Protection Function
Over voltage protection (OVP) Setting range: 5.00 V to 88.00 V
OVP Setting accuracy: 80 mV
Over current protection (OCP) Setting range: 5.00 A to 187.00 A
OCP Setting accuracy: 340 mA
Over power protection (OPP) Setting range: 100 W to 5500 W
OPP Setting accuracy: 50 W
Over voltage limit (OVL) Setting range: 0.00 V to 84.00 V
Under voltage limit (UVL) Setting range: 0.00 V to 84.00 V
Over current limit (OCL) Setting range: 0.00 A to 178.50 A
Under current limit (UCL) Setting range: 0.00 A to 178.50 A
