GW INSTEK PEL-3535H ການໂຫຼດໄຟຟ້າ DC (5250W)
Voltage: 0V～800V
Current 0~262.5A
Power: 5250W
Input Resistance: 0.648MΩ
CC Mode
Operating Range
H 0~262.5A
M 0~26.25A
L 0~2.625A
Accuracy of Setting
H,M ±(0.2 % of set + 0.1 % of f.s*1) + Vin*2/ 3.24MΩ
L ±(0.2 % of set + 0.1 % of f.s) + Vin*2/3.24 MΩ
Resolution
H 10mA
M 1mA
L 0.1mA
CR mode
Operating Range
H 52.5S~0.9mS(19.0476mΩ~1.11111kΩ)
M 5.25S~0.9mS(190.476mΩ~11.1111kΩ)
L 525mS~0.9mS(1.90476Ω~111.111kΩ)
Accuracy of Setting
H, M ±(0.5 % of set*6 + 0.5 % of f.s.*1) + Vin*2/3.24MΩ
L ±(0.5 % of set*6 + 0.5 % of f.s.) + Vin*2/3.24MΩ
Resolution
H 900uS
M 90uS
L 9uS
CV mode
Operating Range
H 5V~800V
L 5V~80V
Accuracy of Setting
H, L ±(0.2 % of set + 0.2 % of f.s)
Resolution
H 20mV
L 2mV
CP mode
Operating Range
H 525W~5250W
M 52.5W~525W
L 5.25W~52.5W
Setting Range
H 0W~5250W
M 0W~525W
L 0W~52.5W
Accuracy of Setting
H, M ± (0.6 % of set + 1.4 % of f.s) + Vin*Vin*3/3.24MΩ
L (0.6 % of set + 1.4 % of f.s) + Vin*Vin*3/3.24 MΩ
Resolution
H 400mW
M 40mW
L 4mW
Dimensions (mm) & Weight: 598(W) x 877(H) x 706(D), 127.5kg
