GW instek PEL-300 DC Electronic Load (60V, 60A, 300W)

Name: GW instek PEL-300 DC Electronic Load (60V, 60A, 300W)
Brand: GW INSTEK

ModelPEL-300

ຕິດຕໍ່

ຈຳນວນ

ການຊຳລະເງິນທີ່ປອດໄພ

ການຮັບປະກັນຄຸນນະພາບ

ປ່ຽນ ແລະ ສົ່ງຄືນງ່າຍ

ມີບໍລິການຈັດສົ່ງ

.
Accessories: ; User Manual x 1; Power Cord x 1

RATING
Operating Volatge	DC 3 ~ 60V
Operating Current	6mA ~ 60A
Operating Power	1 ~ 300W
MInimum Operation	3V
CV MODE
Operating Range	DC 3 ~ 60V
Setting Accuracy	±(0.1% + 40mV)
Setting Resolution	20mV
CC MODE
Operating Range	6mA ~ 60A
Setting Accuracy	±(0.5% + 100mA) for 6.02A ~ 60A ±(0.1% + 10mA) for 0.602A ~ 6A ±(0.1% + 1mA) for 6mA ~ 0.6A
Setting Resolution	20mA for 6.02A ~ 60A 2mA for 0.602A ~ 6A 0.2mA for 6mA ~ 0.6A
CR MODE
Operating Range	50mΩ ~ 1kΩ
Setting Accuracy	±(5% + 1Ω) for 100.33Ω ~ 1kΩ ±(5% + 100mΩ) for 10.033Ω ~ 100Ω ±(5% + 10mΩ ) for 1.0033Ω ~ 10Ω ±(5% + 1mΩ ) for 50mΩ ~ 1Ω
Setting Resolution	330mΩ for 100.33Ω ~ 1kΩ 33mΩ for 10.033Ω ~ 100Ω 3.3mΩ for 1.0033Ω ~ 10Ω 0.33mΩ for 50mΩ ~ 1Ω
DYNAMIC OPERATION CC MODE ONLY
Frequency Range	1Hz ~1kHz
Resolution	5Hz for 100Hz ~1kHz 0.5Hz for 10Hz ~100Hz 0.05Hz for 1Hz ~10Hz
Duty Range	10% ~ 90%
Resolution	1%
VOLTAGE READBACK
Accuracy	±(0.1% + 60mV)
Resolution	20mV
CURRENT READBACK
Accuracy	±(0.5% + 100mA) for 6.02A ~ 60A ±(0.1% + 10mA) for 0.602A ~ 6A ±(0.1% + 1mA) for 6mA ~ 0.6A
Resolution	20mA for 6.02A ~ 60A 2mA for 0.602A ~ 6A 0.2mA for 6mA ~ 0.6A
MEMORY
	100 sets
TIMER
Range	1 second ~ 999 minutes 59 seconds
Resolution	1 second
Function	for load on
POWER SOURCE
	AC100V/120V/220V/240V±10%, 50/60Hz
ACCESSORIES
	User manual x 1 Power cord x 1
DIMENSIONS & WEIGHT
	255(W) x 145(H) x 346(D)mm Approx. 9kg

Datasheet
