Test Frequency: DC, 10Hz ~ 1MHz; 6 digits, ±0.007%
Output Impedance: 25Ω / 100Ω
Basic Accuracy: ±0.08%
Test Speed: MAX 2.5ms (>10kHz), FAST: 50ms (>20Hz), MEDIUM: 100ms, SLOW: 300ms, SLOW2: 600ms
Test Signal:
- AC Voltage: 10mV ~ 2Vrms (FREQ. ≦ 1MHz, RO=100Ω), 10mV ~ 1Vrms (FREQ. ≦ 1MHz and RO=25Ω)
- AC Current: 100μA ~ 20mArms (RO=100Ω), 400μA ~ 40mArms (RO=25Ω)
- DCR Voltage: 1Vdc (40mA max.)
Measurement Parameters: (Z), (Y), C, L, X, B, R, Q, D, G, θ, Rdc
List Measurement
Listed Steps: 15
Listed Parameters: Freq/Vac/Iac/DC Bias/Comp/BIN
Trigger: AUTO, REPEAT, SINGLE
Sweep Measurement
Swept Graphical: Two of measurement parameters
Swept Parameters: Freq/Vac/Iac, Keep Trace
Display: 7" LCD color display (800x480)
Interface: GPIB/LAN/RS-232/ USB Host & device Handler
Power Source: AC 100V~240V, 50/60Hz; Consumption: 65VA (max.)
Dimensions & Weight: 346 (W) X 145 (H) X 335 (D) mm; Approx. 3.3kg
