FREQUENCY:
- Frequency Span:
+ Range: 9 kHz to 1.8 GHz
+ Resolution: 1 Hz
+ Span Range: 0 Hz, 100 Hz to max. frequency of instrument
- Internal Frequency Reference:
+ Span Range: 10.000000 MHz
+ Reference Frequency Accuracy: ± [(days from last calibrate × freq aging rate) + temperature stability + initial accuracy ]
+ Temperature Stability: < 2.5ppm (15°C to 35°C)
+ Aging rate: < 1ppm/year
- SSB Phase Noise:
+ 10 kHz: < -82 dBc/Hz
+ 100 kHz: < -98 dBc/Hz(Typical)
+ 1 MHz: < -110 dBc/Hz(Typical)
- Bandwidth:
+ Resolution Bandwidth: 10Hz to 500kHz (1-10 steps by sequence), 1MHz, 3MHz (Option) 200 Hz, 9 kHz, 120 kHz, 1 MHZ for EMI(-6dB)
+ RBW Uncertainty: < 5%, typical (RBW 1 MHz) ≤
+ Resolution Filter Shape Factor(60dB:3dB): < 5:1 typical (digital and close to Gaussian shape)
+ Video Bandwidth(VBW): 10 Hz to 3 MHz
AMPLITUDE:
- Amplitude and Level:
+ Amplitude Measurement Range: DANL to +10 dBm, 100 kHz to 1 MHz, Preamp Off; DANL to +20 dBm, 1 MHz to1.5 GHz, Preamp Off
+ Reference Level: -80 dBm to +30 dBm, 0.01dB by step
+ Preamp: 20 dB, nominal, 9 kHz to 1.8 GHz
+ Input Attenuation: 0 to 40 dB, in 1 dB step
+ Max Input DC Current: 50 VDC
- Display Average Noise Level:
+ Max Continuous Power: +30dBm, average continuous power
Preamp Off: 1 MHz ~ 10 MHz: -130 dBm (Typical)
10 MHz ~ 1 GHz: -130 dBm (Typical)
1 GHz ~ 1.8 GHz: -128 dBm (Typical)
Preamp On: 1 MHz ~ 10 MHz: -150 dBm (Typical)
10 MHz ~ 1 GHz: -150 dBm (Typical)
1 GHz ~ 1.8 GHz: -148 dBm (Typical)
- Frequency Response:
+ Preamp Off(fc ≥ 100 kHz): ±0.8 dB:±0.4 dB, Typical
+ Preamp On(fc ≥ 100 MHz): ±0.9 dB:±0.5 dB, Typical
SWEEP
:
- Time:
+ None-zero Span: 10 ms to 3000 s
+ Zero Span: 1 ms to 3000 s
- Span Mode: Continue, Single
TRACKING GENERATOR (OPTION 01)
:
- Tracking Generator Output:
+ Frequency Range: 100 kHz to 1.8GHz
+ Output Power Level Range: -30 dBm to 0 dBm
+ Output Power Level Resolution: 1 dB
+ Output Flatness: ± 3 dB
+ Maximum Safe Reverse Level: Average total power: 30 dBm, DC : ±50 VDC
DEMODULATION:
- Audio Demodulation:
+ Frequency Range: 100 kHz to 1.8 GHz
+ Demodulation Type: FM/AM/USB/LSB
- AM Measurement:
+ Frequency Range: 10MHz to 1.8GHz
+ Modulation Rate: 20Hz to 100kHz
+ Modulation Rate Accuracy: 1Hz, nominal(Modulation rate < 1 kHz); <0.1% modulation rate, nominal(Modulation rate 1 kHz)
+ Depth: 5% to 95%
+ Depth Accuracy: ±4%, nominal
- FM Measurement:
+ Frequency Range: 10 MHz to 1.8 GHz
+ Modulation Rate: 20 Hz to 100 kHz
+ Modulation Rate Accuracy: 1Hz, nominal(Modulation rate < 1 kHz); <0.1% modulation rate, nominal(Modulation rate 1 kHz)
+ Deviation: 20 Hz to 200 kHz
+ Deviation Accuracy: ±4%, nominal
FREQUENCY COUNTER:
+ Counter Resolution: 1Hz, 10Hz, 100Hz, 1kHz
+ Accuracy: ±(frequency indication × frequency reference accuracy+ counter resolution
INPUTS AND OUTPUTS:
- RF Input:
+ Impedance: 50 Typical
+ Connector: N Type Female
- Tracking Generator Output:
+ Impedance: 50 Typical
+ Connector: N Type Female
- Reference Input:
+ Connector: BNC Female
+ 10MHz Reference Amplitude: 0 dBm to +10 dBm
- USB:
+ USB Host: A Plug, USB 2.0 (Host End)
+ USB Device: B Plug, 2.0 Version
- VGA:
+ Connector: 15-pins, D-SUB(female)
+ Resolution: 800*600, 60 Hz
GENERAL SPECIFICATION:
- Display:
Type: 10.4 inches, TFT LCD, 800*600 (SVGA), 65536 colors
- Remote Control:
+ USB: USB TMC
+ LAN: 10/100Base, RJ-45
- Mass Memory:
Internal Memory: 256M Bytes
- Temperature:
+ Operating Temperature: 0 °C to 40°C
+ Storage Temperature: -20°C to 70°C
- Appearance:
+ Dimensions & Weight: 421mm(W) × 221mm(H) × 115mm(D)/Approx. 5.0 kg(without package)
