OUTPUT RATING:
Output Voltage: 0.000 V to 32.000 V
Output Current: 0.0000 A to 3.0000 A
Output Power: 96 W
CONSTANT VOLTAGE OPERATION
Line Regulation: ± (0.01 % of setting + 3 mV)
Load Regulation:
≤ 0.01 % + 3 mV (rating current ≤ 3 A)
≤ 0.02 % + 5 mV (rating current > 3 A)
Transient Response: < 100 µs
Ripple Noise: 0.8 mVrms
Setting Range: 0 V to 33.600 V
Rise Time: ≤ 100 ms
Fall Time: ≤ 100 ms
Maximum Remote Sensing Compensation Voltage (Single Line): 0.5 V
Temperature Coefficient (TYP.): 300 ppm/℃
CONSTANT CURRENT OPERATION
Line Regulation: ≤ 0.1 % + 3 mA
Load Regulation: ≤ 0.1 % + 3 mA
Setting Range: 0 A to 3.1500 A
Ripple Noise (Arms): ≤ 2 mArms
Temperature Coefficient (TYP.): 300 ppm/℃
GENERAL SPECIFICATIONS
Display: 2.4-inch TFT LCD
Interface :
LAN: MAC Address, Gateway IP Address, Instrument IP
Address, Subnet Mask
USB: Type A: Host, Type B: Slave, Speed: 1.1/2.0, USB-CDC/TMC
GPIB (Factory Optional): SCPI-1993, IEEE 488.2 compliant interface
Power Source: AC (100 V, 120 V, 220 V, 240 V) ± 10 %, 50 or 60 Hz
Power Consumption: 300 VA
Max. Inrush Current: 30 A max or less
Dimensions & Weight: 107 mm x 124 mm x 313 mm (W x H x D) (not including protrusions), Approx. 5.5 kg
