Cutting width: 130 cm / 51.2"
Max. cutting height without assistance pressing plate: 13 cm / 5.1"
Max. cutting depth: 130 cm / 51.2"
Min. cutting depth without assistance pressing plate: 3 cm / 1.2"
Extended length of working table: 73 cm / 28.7"
Height of working table: 86–91 cm / 33.8"–35.8"
Machine width including side working table: 266 cm / 104.7"
Total length of working table: 241 cm / 95"
Cutting speed: 45 times/min (double cutting)
Max. paper pressure: 40000 N
Power of main motor: 4 kW
Motor for paper feeding: 0.75 kW
Air pump: 0.75 kW
Machine weight: 3200 kg
Overall dimension (L×W×H): 258 × 151 × 189 cm / 102" × 60" × 75"
Blade specifications (L×W×H): 152 × 12.7 × 1.27 cm / 59.8" × 5" × 0.5"
Imported ball lead screw: Standard
Imported double guide-rail slot-less working table: Standard
Main and assistance working table with air ball and chrome-plated: Standard
IR photoelectric protection and hands operating protection: Standard
Ejecting device for cutting stick: Standard
Inside electronic knife locker: Optional
Safe and convenient knife replacement system: Standard
Overloading protection device for cutting: Standard
Flat worm speed reducer transmission: Standard
Optical knife alignment: Standard
PLC control system: Standard
Imported hydraulic system: Standard
Imported electric components: Standard
Enlarge side working table: Optional
Soft pressure: Optional
Optimize function: Without
