Imaging and optics:
Core Technology Item : Equipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm SharpIR 2.0
Detector type : VOx, 7.5 to 14μm
Infrared resolution : 1024×768@12μm
Super resolution: Yes, Upgrade to 2048×1536
NETD: 15mK
Frame rate: 50Hz/9Hz
Focal length : 27.7mm
Field of view: 25°×20°
IFOV : 0.43mrad
Min. object distance : 0.3m
D:S: '2326:1
Focusing mode : Manual / Automatic / Touch autofocus / Continuous autofocus
Digital zoom : 1x to 50x
Measurement and analysis:
Measurement range : Support auto-switching: -40°C to 150°C, 0°C to 800°C, Optional 400°C to 2500°C (High temperature lens is required)
Measurement accuracy : ±1°C or ±1%, whichever is greater
Analyzed target: 35 in total (Spot/Line/Area)
Alarm: Full screen temperature threshold alarm (Image, Voice, Color and Flash)
Others : Isothermals, Smart Stroke, Intelligently calculate the area, Color Highlighting
Image display:
Display screen : 5.5’’ LCD, touch screen, 1920×1080
Eyepiece: OLED screen, 1920×1080
Image mode : IR, VIS, MIF, PIP
Color palettes : 15: White Hot, Iron Red, Arctic, Rainbow 2, Hot Iron, Rainbow 1, Fulgurite, Medical, Tint, Black Hot, Blue Hot, Sepia, Green Hot, Ice and Fire, Amber; Customized
Image adjustment : Level span mode: Automatic, Semi-automatic, Manual, Local dimming
Digital camera: Dual visible light, up to 16MP
Functions:
Laser: Laser indication; Laser ranging 0.1m to 35m
Recording function : Photo (image stitching) and Video (infrared & visible light)
Cloud Services : Available
Others: Customized physical button, NFC connection, OTA update
Storage and transmission:
Storage media: Built-in (64 GB) and external SD card (128 GB and up to 256 GB)
Image storage : JPG with temp info
Video storage : MP4 format (without temp info) can be used to record audio synchronously; Irgd (with temp info)
External interface : USB-C, DC (12V) , SD card slot, Micro HDMI, Tripod socket
Wi-Fi : Yes, it can be connected to the mobile terminal for image and real-time video transmission
Cellular network : 5G module (optional)
Bluetooth : Bluetooth 5.0, support image transmission (only for Android)
Power system:
Battery type : Lithium-ion rechargeable battery
Operating time: 4 hours
Environmental parameters:
Working temperature : -20°C to 50°C
IP rating : IP54
Physical parameters:
Hardware : Wi-Fi, Illuminator, Microphone, Speaker, Electronic Compass, GPS, Status screen
Weight: 1.78kg (with standard lens and battery)
Size : 191×171×118mm
Software kit : PC: ThermoTools; Mobile: FocusIR (iOS/Android)
Standard: A device (with lens), Lens front and back cover, Lithium-ion battery (2 pcs), Desktop charger, Power adapter, Adapter plug, USB-A to USB-C cable, USB-C to Ethernet Adapter, Micro HDMI to HDMI cable, SD card (128 GB), Wrist strap, Shoulder strap, Safety box, Carrying bag, Quick Start Guide, Warranty Card, Inspection Report, Calibration Certificate
Options : Optional lenses: Wide-angle (45°), Medium Telephoto (15°), Telephoto (7°), TwinView DFOV (25°+15° / 25°+45°), High-temperature, Macro; Tripod, Bluetooth earphone, 5G module
