Imaging and optics
Detector type: VOx, 7.5 to 14μm
Infrared resolution: 640×512@12μm
Super resolution: Yes, Upgrade to 1280×1024
NETD: 30mK
Frame rate: 30Hz/ 9Hz
Focal length: 17mm
Field of view: 25°×19°
IFOV: 0.71mrad
Min. object distance: 0.3m
D:S: 1408:1
Focusing mode: Manual / Automatic / Touch autofocus / Continuous autofocus
Digital zoom: 1.1x to 40x
Measurement and analysis
Measurement range: Support auto-switching: -40°C to 150°C, 0°C to 650°C, Optional 400°C to 2500°C (High temperature lens is required)
Measurement accuracy: ±1°C or ±1%, whichever is greater
Analyzed target: 30 in total (Spot/ Line/ Area)
Alarm: Full screen temperature threshold alarm (image, voice and flash)
Parameter settings: Emissivity, reflected temperature, target distance, humidity, atmospheric temperature, optical transmittance, dew point
Others: Customized physical button, Intelligent diagnosis, NFC connection, OTA update
Image display
Display screen: 5’’, 1920×1080 pixel touchscreen LCD
Eyepiece: 1920×1, 080 OLED screen
Image mode: IR, VIS, MIF, PIP
Color palettes: 15: White Hot, Iron Red, Arctic, Rainbow 2, Hot Iron, Rainbow 1, Fulgurite, Medical, Tint, Black Hot, Blue Hot, Sepia, Green Hot, Ice and Fire, Amber, Customized
Image adjustment: Level span mode: Automatic, Semi-automatic, Manual
Digital camera: Dual visible light, up to 13 MP
Functions
Laser: Laser (Indication, Ranging 0.1m to 35m)
Recording function: Photo (image stitching) and Video (infrared & visible light)
Cloud Services: Available
Storage and transmission
Storage media: Built-in (64 GB) and external SD card (128 GB and up to 256 GB)
Image storage: JPG with temp info
Video storage: MP4 format (without temp info) can be used to record audio synchronously; Irgd (with temp info), up to 20 Hz (optional) for temperature analysis
External interface: Type-C, DC (12V) , SD card slot, Micro HDMI, UNC ¼"-20 (Tripod mounting)
WIFI: Yes, it can be connected to the mobile terminal for image and real-time video transmission
Cellular network: 5G module (optional)
Bluetooth: Bluetooth 5.0, support image transmission (only for Android)
Power system
Battery type: Lithium-ion rechargeable battery
Operating time: 4 hours
Charging mode: The device can be charged through desktop charger after shutdown.
Charging time: 90% of full charge in 2.5 hours, revealed by the status screen
Environmental parameters
Working temperature: -20°C to 50°C
IP rating: IP54
Physical parameters
Hardware: Illuminator, Microphone, Speaker, Electronic Compass, GPS, Status screen
Weight: 1.86kg (with battery)
Size: 191×171×118mm
Software kit: PC: ThermoTools; Mobile: Thermography (iOS/Android)
Standard: A device (with lens), Lens front and back cover, Lithium-ion battery (2 pcs), Desktop charger, Power adapter, Adapter plug (5 pcs) , TYPE-C USB cable, Micro HDMI cable, Type C to GE cable, SD card (128 GB) , Wrist strap, Shoulder strap, Carrying case, Safety box, Packaging list, Quick Start Guide, Data download card (analysis software & user manual), Certificate of approval, Factory certificate
Options: Battery, optional lens (45°, 15°, 7°, high-temperature lens, macro lens), Carrying bag, Tripod, Bluetooth earphone, 5G module
