Acoustic sensor
Microphone array: 128 low-noise MEMS microphones
Bandwidth: 0 kHz to 65 kHz, Adjustable range
SPL range: 0~120 dB
Frame rate: 50Hz/9Hz
Detection mode: Partial Discharge / Gas Leak
Thermal sensor (Thermal module required)
Core Technology Item: Equipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm SharpIR 2.0
Detector type: VOx, 7.5 to 14μm
Infrared resolution: 640×512@12μm
Super resolution: Yes, Upgrade to 1280×1024
NETD: 15mK
Focal length: 13mm/17.7mm
Measurement range: Support auto-switching: -40°C to 150°C, 0°C to 650°C
Measurement accuracy: ±2°C or ±2%, whichever is greater
Image display
Display screen: 10.1’’ LCD, touch screen, 1920×1200
Digital camera: 13MP
Digital zoom: 1.1x~20x
Image mode: AU, IR, MIF, PIP
Functions
Laser: Support laser indication, laser ranging range of 0.1m to 35m
Recording function: Photo and Video
Cloud Services: Available
OTA: Available
Storage and transmission
Storage media: External SD card (128 GB and up to 256 GB)
Image storage: JPG with temp info
Video storage: MP4 format (without temp info) can be used to record audio synchronously; Irgd (with temp info), up to 30 Hz (optional) for temperature analysis
External interface: USB-C, SD card slot, Tripod socket
WIFI: Yes, it can be connected to the mobile terminal for image and real-time video transmission
Bluetooth: Bluetooth 5.0, support image transmission (only for Android)
Power system
Battery type: Lithium-ion rechargeable battery
Operating time: Built-in battery + External battery: 5 hours
Environmental parameters
Working temperature: -20°C to 50°C
IP rating: IP54
Physical parameters
Hardware: Wi-Fi, Illuminator, Microphone, Speaker, Electronic Compass, GPS
Weight: Acoustic Laser Rangefinder Version: 1.88kg; Acoustic Focus-free Thermal Version: 1.97kg; Acoustic Autofocus Thermal Version: 2.18kg
Size: 309×243.5×74mm/309×243.5×100mm
Software kit: PC: ThermoTools; Mobile:FocusIR (iOS/Android)
Package Contents: Device (acoustic, module optional), Customized Batteries ×2, Desktop Charger,Power Adapter with Plugs, USB-A to USB-C Cable, USB-C to USB-C Cable, Micro HDMI to HDMI Cable, RJ45 Ethernet Patch Cable, Docking Station, SD Card (128GB), Shoulder Strap, Hand Strap, Carrying Case, Safety Box, Quick Start Guide, Inspection Report, Calibration Certificate, Warranty Card
Optional Items: Tripod, Bluetooth Earphones, Optional module (Laser Rangefinder, Focus-free Thermal, Autofocus Thermal)
