Grandwaytelecom FHP2P04 ເຄື່ອງມວນກຳລັງແສງ PON (+13~–10 dBm; +13~–30dBm; +13~–50dBm; +17~–50dBm)
Calibrated Wavelength: 1270nm; 1310nm; 1490nm; 1577nm
Measuring Range (dBm) CW mode: +13 ~ –10; +13 ~ –30; +13 ~ –50; +17 ~ –50
Measuring Range (dBm) Burst mode:+13 ~ –10; +13 ~ –30
Spectral Passband:1270±10nm; 1310±20nm; 1490±10nm; 1577±6nm
Insertion Loss: ≤1.5dB
Uncertainty: ≤0.5dB
Display Resolution: 0.01dBm
Display Unit: dBm/dB
Threshold Settings: Support 10 groups user defined (Pre-set by PC software)
Display: 2.5-inch LCD
Optical Port: 2SC/APC or 2SC/UPC
USB Port: USB Type-C interface for charging and test results upload
Memory Capacity: 700 groups
Wireless: Bluetooth
Power Supply: 2*2500mAh Ni-MH AA battery
External Power Supply: 5V/1A; AC/DC adapter
Working Temp: –10°C ~ +50°C
Storage Temp: –20°C ~ +70°C
Dimension: 160L × 76W × 45H (mm)
Weight: 300g
