AI Module
Test End Setting:
Normal mode (Fiber link map function)
Fiber end is ONU (Test from splitter towards to ONU)
Fiber end is Splitter (Test from ONU towards to splitter)
First connector insertion loss and the ONU/Splitter connectivity state can be tested
ONU Module (ONU Status Identification)
ONU Status Type: ONU Online, ONU Offline, No ONU (Disconnected), Rogue ONU
OTDR
Wavelength: 1550nm/1625nm/1650nm is optional (3 select 1)
Dynamic Range: 20dB
Deadzone: Event dead zone: 1m, Attenuation dead zone: 4m
Test Range: 500m~120km
Pulse Width: 3ns~20us
Distance Accuracy: ±(1m + Test distance × 3×10⁻⁵ + Sampling resolution) (excluding IOR uncertainty)
10G PON Optical Power Meter
Calibrated Wavelength: Simultaneously display 1490nm, 1577nm and 1270/1310nm power
Test Range: -40~+10dBm
Test Accuracy: ±0.35dB
Stable Laser Source
Wavelength: Consistent with OTDR
Output Power: ≥-12dBm
Working Mode: CW/270Hz/1kHz/2kHz
VFL
Wavelength: 650nm ± 10nm
Output Power: 10mW; CW/1Hz/2Hz
RJ45 Cable Test
Line Sequence Standard: TIA-568A or TIA-568B standard
Others
Optical Interface: 2SC/UPC port, 12.5mm universal port for VFL
Electric Interface: 2*RJ45 port, RJ45 remote module, Type-C charging/data port
Wireless: Bluetooth connection with Android phone app
Display: 3.5 inch color LCD
Data Storage: Pluggable 16GB micro SD card
Battery: 5000mAh lithium battery
Working Condition: -10°C ~ +50°C / 0~85% (Non condensing)
Dimension/Weight: 192.9(L) × 93.8(W) × 47(H)mm / 0.58kg
