Processing channels: 64 channels (for calculating energy, power and costs)
LON Meter Inputs: Up to 64 LON devices
Interfaces: RS-232; RS-485; ECS LAN; LON; Ethernet: 100 MBit/s with ECL access via TCP/IP (4 sockets)
Software: Energy Control Language (ECL) for programming evaluations
Outputs
Relay outputs: Two S0 semiconductor relays: max. 50 V DC, 200 mA, bipolar
Mechanical Design: W 45 mm x H 100 mm x D 114 mm
Mounting: To top-hat rail per EN 50022 / 35mm
Wire Connections
Grid dimension: 3.5 mm to 5 mm (depending on terminal)
Rigid/flexible cross-section: 0.14 to 2.5 mm²
Tightening torque: 0.22 to 0.6 Nm (depending on terminal)
Memory: MRAM: 4 MB
Ambient Conditions
Operating temperature range: -10 ... +55 °C
Storage temperature range: -25 ... +70 °C
Relative humidity: < 75%
Elevation: Up to 2000 m
Place of use: Indoors
Pollution degree: PD2
