Designation
Auxiliary voltage 24 V DC, Ethernet crossover cable, screwdriver, wire mounting tool, installation instructions, manual and SMARTCONTROL manager on CD; with Modbus TCP expansion
Memory capacity: 2 MB flash ring buffer (expandable with 4 GB microSD card)
Mains power: 12 ... 24 V DC (Power consumption: < 2.5 W)
Operating conditions: 5 ... 50 °C, no condensation
Housing material: Steel sheet metal (226 x 210 x 70 mm)
Protection: IP 20
Modbus TCP Expansion: Support for Modbus TCP protocol via Ethernet
OPC Server Support: Integrated with SMARTCONTROL OPC Server
Analog Inputs: 8 (0...20 mA or 0...10 V)
Digital Inputs: 8 (active or passive)
Temperature Inputs: 8 (for PT1000 sensors)
Switching Outputs: 2 semiconductor relays
Interfaces: Ethernet (Modbus TCP), RS232 (M-Bus), RS485 (Modbus RTU)
Analog Accuracy: typical ±0.05 V
Temperature Accuracy: Better than ±0.5° C
Digital Input Pulse Sequence: At least 10 ms / 10 ms (0/1)
RTC Battery: CR 2032 3 V (Replacement every 5 years)
Programming: Graphic programming using function blocks (SMARTCONTROL manager)
