Flow measurement
Flow rate: 0.01 ml/h … 1000 ml/h
Flow resolution: 0.01 ml/h
Volume measurement
Range: 0 to 2000 ml
Resolution: 0.001 m
Pressure measurement
Range: –5 psi … 50 psi
Resolution: 0.001 psi
Power supply
AC power: 100 … 240 VAC, 50/60 Hz
AC power adapter: 12 VDC, 1.5 A
Battery: Internal rechargeable lithium-ion battery pack
Battery runtime: 12 hours idle, 3 … 4 hours of continuous testing
Battery charging duration: approx. 4 hours (full charge)
Ambient conditions
Operating temperatures: +15 … +40 °C
Storage temperatures: 0 … +50 °C
Relative atmospheric humidity: 10% … 90%, no condensation allowed
Elevation: max. 3000 m
Electromagnetic Compatibility (EMC)
Interference emission: EN 61326-1, class A
Interference immunity: DIN EN IEC 61326-1
Mechanical Design
Housing (W × H × D): Approx. 121.9 × 109.2 × 157.5 mm
Weight: Approx. 1.4 kg
Display: 4.3” color touchscreen 480 × 270 px
Data Interfaces
Wireless interface:
Bluetooth®
Frequency range: 2.4 GHz … 2.482 GHz
Transmission intensity: max. 3 dBm
COM port: Micro-USB type B
Internal memory: 250 measurement
