Gossen Metrawatt PROFiTEST MF XTRA 0105-Set ການທົດສອບການຕິດຕັ້ງໄຟຟ້າ ແລະ ລະບົບຕ່າງໆ (65 V ~ 500 V AC; 15.4 Hz ~ 420 Hz)

System voltage range: 65 V to 500 V AC (single-phase and three-phase systems)

Frequency measurement range: 15.4 Hz to 420 Hz

Display: Context-sensitive color graphic display

Storage capacity: Up to 50,000 data records

Test sequences: Preconfigured and user programmable automatic test sequences

Loop and line impedance measurement: With DC bias magnetization

Insulation resistance measurement: Using nominal voltage, with variable or rising test voltage

Low-resistance measurement: With automatic polarity reversal

Residual current device (RCD) testing: AC/DC sensitive RCDs, RCCBs (types AC, A, A-EV, F, F-EV, B, B+, B-MI), selective S, SRCDs, PRCDs, Schukomat, Sidos, types G/R

RDC-DD and RCMB testing: According to IEC 62955 and IEC 62752

Earth resistance measurement: Mains operation method

Charging station testing: According to IEC 61851-1 (with suitable test adapter)

Connectivity: USB interface and push-print function for data transmission

Data management: Measurement storage, system configuration, and report generation

Safety feature: Protective conductor (PE) detection for enhanced user safety

Interface: USB port for data transfer and documentation

Datasheet

Delivery

1 PROFiTEST MF XTRA

1 Earthing contact plug insert (country-specific)

1 Two-pole measuring adapter

1 Cable for expansion into a 3-pole adapter (PRO-A3-II)

2 Alligator clips

1 Neck strap

1 Set of rechargeable batteries (Z502H)

1 Charger (Z502R)

1 Condensed operating instructions

1 Supplementary sheet with safety information

1 DAkkS calibration certificate

1 USB interface cable

1 METRAVOLT 12D+L

1 SORTIMO plastic system case with insert

1 IZYTRONIQ Business Professional software

1 IZYTRONIQ coupon for 12-month cloud subscription
