Power Supply: Rechargeable NiMH battery, 4 × 1.2 V type AA, round cells (recommended: Ansmann maxE 2500 mAh)
Input Impedance
Measuring input S+: 1.6 MΩ
Measuring input S-: >10 MΩ
Ambient Conditions
Operating temperatures: +5 … +40 °C
Storage temperatures: −20 … +60 °C
Relative humidity: max. 75 %, no condensation allowed
Elevation: max. 2000 m
Electrical Safety
Measuring category: 600 V CAT III
Pollution degree: 2
Protection class: II
Fuse link: 1 × SIBA 600 V/10 A FF
Test voltage: Test voltage at measuring connection P+ may not exceed 24 VDC.
Electromagnetic
Compatibility (EMC)
Interference emission: EN 61326-1 class A
Interference immunity: EN 61326-1, EN 61326-2-1
Protection: Housing IP40
Housing (W × H × D): approx. 9.6 × 15.4 × 3.3 cm
Weight: approx. 0.45 kg (without rubber holster)
Display: LCD, monochrome, luminous
Data Interfaces
IrDA: Connection for DMA 35 Basic density meter (version 3)
RFID: Connection for RFID tag
Frequency range: 125 kHz
Transmission intensity: 34.3 dbμV/m or -17.2 dbμA/m, respectively
Wireless interface: Connection for PC, headset and DMA 35 density meter (version 4)
Frequency range: 2.4 - 2.4835 GHz
Transmission intensity: max. + 3 dBm
Internal Memory up to 300,000 data records
