Inputs
Nominal Current: 1 … 5 A
Nominal Voltage: 57.7 … 400VLN, 100 … 693VLL
Nominal Frequency: 42 … 50 … 58Hz, 50.5 … 60 … 69.5Hz
Power Supply Variants
Nominal Voltage: 110 … 230 V AC, 130 … 230 V DC
Consumption: ≤ 30VA, ≤13W
Uninterruptible Power Supply (UPS) (Optional)
Type (3.7 V): Varta Easy Pack Ezpackl, Ul Listed Mh16707
Types Of Connection
Connection configurations:
• Single phase or split phase (2-phase system)
• 3 or 4-wire balanced load
• 3-wire balanced load [2U, 1I]
• 3-wire unbalanced load, Aron connection
• 3 or 4-wire unbalanced load
• 4-wire unbalanced load, Open-Y
Weight: 800g
I/O-Interface
Analog Outputs: Optional
Relays: Optional
Digital Inputs Passive: 12/24 V DC (30 V Max.)
Digital Inputs Active: Optional
Digital Outputs: 12/24 V DC (30 V Max.)
Fault Current Monitoring For Grounded Systems: Optional
Temperature Inputs: Optional
Interfaces
Ethernet: Standard
Bus Connection: Ethernet (Modbus/TCP, web server) + RS485 (Modbus/RTU)
