Unit capacity, m3/h (gpm): 0.1…1 (0.44… 4.4)
Kinematic viscosity of product, mm2/s (St), not more than: 150 (1.5)
Operating temperature, °С (°F), not more than: 180 (356)
Maximum pressure, bar (psi), not more than: 6 (87)
Product operating volume, L (gal): 5 (1.3)
Shaft seal type: mechanical
Rotor/stator tooling type: nozzle
Replaceable knife kit: optional
Knife axial gap (preset), mm (in): 0.2…2 (8·10-3… 8·10-2)
Knife radial gap, mm (in): 0.25 (10-3)
Knife tip speed, m/s (mph), not more than: 50 (112)
Mill shaft and bearing rotation speed, rpm: 6,800
Electric motor shaft rotation speed, rpm: 3,400
Drive power, kW: 3.3
Power voltage, V: custom
Dimensions, mm (in), not more than:
· length: 550 (22)
· width: 600 (24)
· height: 850 (34)
Weight, not more than, kg (lb): 75 (165)
